SU - 6800 Mini
Small in stature, big on features.
Small in stature, big on features.
The SU-6800 Mini is a compact, rugged GPS tracking device that has been designed for tracking containers, trailers, skip bins, and other assets where super-long battery life is required without sacrificing the frequency of updates and performance.
The IP-67 rated housing is rugged and UV stable, so the SU-6800 Mini can be mounted on assets that are exposed to rain, dust and marine conditions.
By utilising the latest technology, the SU-6800 Mini can operate in ultra-low power modes, and with an incredible battery life of up to 5 years the SU-6800 Mini can be attached to assets and tracked without needing to change batteries. The SU-6800 Mini has built-in antennas for GPS reception and for cellular communication, a 3D accelerometer, a high-performance GPS that can track both GPS and GLONASS satellites simultaneously and flash memory for storing non-volatile information.
The SU-6800 Mini uses 3 x AA 1.5V “off the shelf” Lithium batteries. These are generally available at retail outlets from manufacturers like Duracell and Energizer. Industrial 1.5V Lithium AA batteries are also available at bulk pricing.
The Lithium batteries have excellent performance and capacity, and allow the SU-6800 Mini to be used in extreme temperatures and climatic conditions that other tracking devices simply cannot operate in.
Detailed Movement Reporting
The amazing flexibility of the SU- 6800 Mini can be set to report locations based on specific needs.
Should the unthinkable happen and your asset goes missing, with a simple click, users can switch to recovery mode and the unit will report it’s live location every 30 seconds or until the battery fail
Flexible configurations just choose the plan to suit your needs.
The SU-6800 Mini can be configured to suit any business need. Configurations can be remotely changed any any time . Configurations are almost limitless . We’ve put together some of the more popular configurations. For heavy duty applications where extended battery life is needs, we recommend the SU-6800
Example 1 – Periodic updates
Using this configuration the SU – 6800 Mini can report a location at regular intervals, for example 4 daily updates
Example 2 – Motion based
With this configuration the SU-6800 Mini will provide a location on movement staff and movement end
Example 3 – Motion based with breadcrumb
All the benefits of the motion based configuration with addition of recording an update every 2 minutes uploading the updates every 30 minutes.
This feature can be added to any profile and provides updates on small movements whilst maximising battery life. Ideal when assets are being moved around a yard
Fully inclusive pricing includes GST Next Business Day Delivery Training Support
Buy on a month to month plan for $299
Buy as a bundle and save up to $112!
with 12 months service
with 12 months service
with 12 months service
No deposit rental from $29 per month
Frequently asked questions
There is no minimum contract period for outright purchases. Cancel at any time. If renting, the contract can be terminated early fro a fee of $99 and the unit must be returned.
Yes, we have Apps for I-phone and Android phones
Yes, you can upgrade or downgrade your plan, charges are pro-rata
We have two options for month to month subscribers:
Option 1 – Suspend Service
We will reduce your service fee to just $5.95 per month. You will keep all historic data along with all customised portal settings, for example geofences .
Option 2 – Cancel and reconnect
This will disconnect your device and remove any historic data and customised portal settings. You are able to reconnect at anytime, however a re-connection fee of $25 applies.
Yes, we are able to provide you with a second data feed to your own server.
Rental for ABN holders only. Rental based on 24 month rental term. Rental can be cancelled at anytime subject to a $99 termination fee and unit return.
Optional Immediate updates on:
- Trip start
- Trip end
The SU-6500 Mini can be remotely switched into Recovery Mode which switches the device to do live tracking and reporting – so that you can get your asset back!
The SU-6500 will track successfully where other devices just give up.
This fantastic technology allows the GPS to predict which satellites are in orbit above it and to dramatically reduce the time-to-first-fix of the GPS, and the overall performance of the GPS, especially in ‘urban canyon’ or forested environments
A future firmware version will allow for harsh G-force detection (like assets being dropped or involved in accidents) and report these to the server
The SU-6500 Mini has the capacity to hold hundreds of geo-fences that can be downloaded to it from the server. The SU-6500 can use this geo-fence information to:
- Implement arrival and departure alerts
- Implement speeding zones with audible warning alerts
- Implement “No-go” and “Keep-out” areas
- Automatically control outputs, for example to switch on warning lights when inside a special area
- Warn drivers when approaching dangerous intersections
- Disable data communications within intrinsically safe areas
Low-profile IP67 rugged housing
The IP67 rated housing is made of sturdy ABS/Polycarbonate plastic to survive bumps and knocks and to survive many years in the sun and weather.
It is low-profile making it easier to mount in the corrugation on containers or concealed on the underside of a trailer, for example.
The housing screws together for easy assembly, and has 2 convenient mounting tabs. It also has ‘strap slots’ allowing the SU-6800 Mini to be cable tied or metal strapped to an asset.
Dimensions: 100 mm x 65 mm x 19 mm
Weight: 160 grams with batterie
The SU-6800 Mini uses 3 x “AA” size 1.5V Lithium batteries which provide a balance between size and capacity
The SU-6800 Mini must be fitted with off-the-shelf 1.5V Lithium batteries. These are readily available from retail outlets, for example Duracell and Energizer.
The SU-6800 Mini can be set to use Adaptive-Tracking technology where the accelerometer and GPS data are used to intelligently work out if it is moving and to send frequent updates, and to scale the update rate down to once per day if the asset is stationary – to preserve battery life.
5 years @ one position per day (at 25°C)
-20°C to +65°C 1
For operation in extreme temperatures, the SU-6800 Mini must be fitted with Lithium batteries. Batteries are affected by temperature extremes and typical performance is dependent on
The SU-6800 Mini uses both the GPS and GLONASS positioning systems simultaneously.
This allows the device to use twice the number of satellites to get a position fix – making it faster and more accurate.
UBLOX MAX-M8Q GPS module
Supports concurrent GPS and GLONASS
72 channel high sensitivity receiver
-167dBm industry leading tracking performance
Optimal hot-start performance
AssistNow Offline aiding data for fast time-to-first-fix and performance in urban canyon environments
The SU-6800 Mini ’s GPS signals are boosted by a special low-noise amplifier (LNA). This allows the SU-5000 H to operate where normal units will fail to receive GPS signal
Even when designing a low-cost device our partners are not prepared to compromise on the performance of the product. You will see the difference if you compare device performance in low signal environment.
CE, RCM, ICASA A Tick
Internal GPS and Cellular RF antennas tuned by the RF laboratories to ensure optimal performance
The 3-axis accelerometer allows the SU-6800 Mini to ‘sleep’ in an ultra-low power state yet still wake-up when movement occurs.
Future firmware versions will allow for harsh G-force detection (like assets being dropped or involved in accidents)
The SU-6800 Mini has enough flash to store over 50,000 data records, and will record information even when out of cellular coverage.
The flash memory is also used to store firmware updates, GPS aiding data, parameters and other important information.
A future firmware version will allow for geo-fences to be loaded into the flash memory of the device and used for geo-fence alerting on the device.
